ILLUSTRATED PARTS LIST
QUANTUM SERIES JUICE DISPENSER
(SEE FIGURE 2)
Item
No. Part No. Name
Refrigeration and Frame Ass’y
1 729011105 Kit Compressor, 120V 60HZ
729011106 Kit Compressor, 230V 50HZ
2 08474 Clip Spring
3 07301046 Washer Ft .468 I.D.
4 08467 Grommet Compressor
5 45163001 Mtr Asy and Cond 115V 60HZ (See
Figure 9)
45163002 Mtr Asy and Cond 230V 50/60HZ
(See Figure 9)
6 7240691 Grommet
7 45148 Baffle Cond (1000 and 2000 Series)
45670 Panel Baffle Cond (3000 Series)
45448 Panel Baffle Cond (4000 Series)
8 289521 Screw No. 8-32 xy 3/8” HHS
9 45073 Dryer
Item
No. Part No. Name
10 45373010 Solenoid Valve 120V 60HZ
45373020 Solenoid Valve 230V 50/60HZ
11 Box Elec Asy (See Figure 11)
12 45105100 Frame (1000 and 2000 Series)
45671100 Frame (3000 Series)
45405100 Frame (4000 Series)
13 07115001 Screw TF 08-32 TRPH 12
14 60342002 Insert Thd 3/8-16
15 2124713 Fitg Stght 3/8MF x 3/8MPT
16 45091001 Valve Water Solenoid 24V
17 03824001 Nut Jam 7/8-14
18 30041001 Fitg Bulkhead
19 04442 Spacer
20 0702609 Screw MA 8-32 BDPH 24
21 7221320 Strain Relief
22 46384 Cord Serv 115V 60HZ
46384001 Cord Serv 220V 50HZ
Manual Part No. 720901120IPL
4-25-2001 Rev: 12-3-01
