Electrical connection
The machine is connected to the earthed 230V / 50Hz socket. K3 HP can be connected to a 10A, max
16A, fuse. Electronic control delays the start approx. 2 minutes.
Starting and operating
• Operating range humidity: 30-100 %RH
• Operating range temperature: +9 °C to +38 °C
• The drier must reach ambient temperature before starting, if stored in colder conditions.
1. Place the drier on a firm and flat surface where it is not at risk of overturning. The surface
should not be sensitive to water as some spillage may occur, for example when handling the
condensation water hose.
2. The drier must be placed at a distance of at least half (0.5) a meter from walls and ceilings to
ensure that air can circulate.
3. If possible, close doors and windows etc. to use all the dehumidification capacity in the
intended space rather than to dry the whole house/building. To minimize power
consumption, try to ensure that the ambient temperature is approximately 20°C.
4. The drier's hose for condensation water is routed to a drain, sink or similar frost-free runoff
for continuous operation.
5. For continuous operation, set the operation selector to I (Man), the upper position. When
using a hygrostat, set the selector to position II (Hyg), the lower position, connect the
hygrostat and set the desired setpoint on it.
6. The ambient temperature must be +9 °C to +38 °C.
7. K3 HP is equipped with demand-controlled defrosting. If ice forms on the evaporator, the
drier defrosts automatically by stopping the machine. The machine restarts automatically
when the evaporator is clear of ice.
If the drier must be used with a hygrostat, the Man/Hyg selector must be set to Hyg (II), the lower
position. Verify that the hygrostat works by raising and lowering its setpoint and confirm that the
drier switches off and on. Then set the desired setpoint.
The machine must be transported upright and must always be upright during operation.
