REQUIRED HARDWARE
A PHILLIPS-HEAD SCREWDRIVER (not included)
B SHORT FAN MOUNTING SCREWS
C LONG FAN MOUNTING SCREWS
Used for installing fans on a radiator
(sold separately)
D ARGB adapter cable / 1-to-3 ARGB adapter cable
*AR RGB can be controlled through the +5V ARGB
header on a compatible motherboard. To utilize
powerful CORSAIR iCUE software a CORSAIR iCUE
lighting controller is required (sold separately).
A B C
FAN INSTALLATION (ARGB)
3 CONNECT ADAPTER CABLE
Turn your system off prior to installing your AR RGB fan.
SINGLE Fan: Connect the RGB LED cable from
the AR RGB fan to the ARGB adapter cable
to enable 5V ARGB (Addressable RGB) 3-pin
header connection.
TRIPLE Fan Kit: Connect the RGB LED cables
from each AR RGB fan in sequence (1>2>3) to
the 1-to-3 ARGB adapter cable.
1
TURN OFF COMPUTER
2 MOUNT AR RGB FAN
Mount the fan inside your case with the
provided mounting screws. Fan mount locations
will vary depending on the case manufacturer.
D
To Next Page
