Corsair H100i v2 User Manual

2
Installing the AMD Mounting Bracket
Note: It is important that the AMD retention bracket be
evenly secured on all sides before installation!
• Remove the integrated Intel mounting bracket by
pushing on the metal piece, turning 1/8th turn,
and pulling away from the copper coldplate (figure 1).
• Install the AMD bracket by aligning the metal teeth,
pushing in, turning 1/8th turn the opposite direction,
and allowing bracket to secure (figure 2).
1/8
I
1/8
J
figure 1 figure 2

Corsair H100i v2 Specifications

General

Radiator Dimensions	276mm x 125mm x 30mm
Fan Dimensions	120mm x 25mm
Noise Level	37.7 dBA
Radiator Material	Aluminum
Fan Airflow	70.69 CFM
Radiator Size	240mm
Tube Length	300mm
Warranty	5 years
Fan Speed	2435 RPM
Compatibility	Intel LGA 1150, 1151, 1155, 1156, 1366, 2011, 2011-3, AMD AM2, AM3, FM1, FM2
Fan Static Pressure	4.65 mmH2O
Type	Liquid Cooling System
Tubing Material	Low-permeation rubber with black sleeving
