Corsair H100i v2 User Manual

1
Installing the AMD Stando Screws
figure 1 figure 2
• Remove the stock AMD top mounting
bracket(s) shown. (figure 1)
• Attach the provided AMD stando. (figure 2)
• Tighten all four screws until firmly secure. (figure 2)
Note: The stock AMD motherboard backplate is used
for AMD installation. AMD stando are black to
dierentiate between Intel stando.
D

Corsair H100i v2 Specifications

General

Radiator Dimensions	276mm x 125mm x 30mm
Fan Dimensions	120mm x 25mm
Noise Level	37.7 dBA
Radiator Material	Aluminum
Fan Airflow	70.69 CFM
Radiator Size	240mm
Tube Length	300mm
Warranty	5 years
Fan Speed	2435 RPM
Compatibility	Intel LGA 1150, 1151, 1155, 1156, 1366, 2011, 2011-3, AMD AM2, AM3, FM1, FM2
Fan Static Pressure	4.65 mmH2O
Type	Liquid Cooling System
Tubing Material	Low-permeation rubber with black sleeving
