Corsair H100i v2 - Connect Pump to USB Header

6
Connect Pump to USB Header
Using the included Corsair Link
™
USB cable,
attach pump unit to a motherboard USB header.
Included Hardware
Highlighted parts for AMD installation only
Note: the H100i v2 comes with the INTEL mounting bracket pre-installed on the pump for quick installation.
x1 INTEL MOUNTING BRACKET
(PRE-INSTALLED)
I
x8 SHORT SCREWS
K
CORSAIR LINK USB CABLE
(Included)
L
x2 SP120L FANS
F
x1 INTEL BACKPLATE
H
x8 LONG FAN SCREWS
A
x4 THUMBSCREWS
E
x4 LGA 2011 STANDOFF
C
x4 LGA 115X / 1366 STANDOFF
B
x16 WASHER
G
x4 AMD BLACK STANDOFF
D
x1 AMD MOUNTING
BRACKET
J
