Corsair H110i User Manual

B
3
Install the Stando Screws
4
Install the Mounting Bracket
Insert the mounting bracket onto the top
of the pump as shown.
Install the provided stando screws. Use G for LGA
1150/1155/1156, and H for LGA 2011. Tighten the screws
until the backplate is secure. Note: Backplate may still
have some leeway depending on your motherboard.
LGA 2011 does not require a backplate.
H
G
LGA2011
LGA 1150/
1155/1156

Corsair H110i Specifications

General

Radiator Size	280mm
Fan Size	140mm
Number of Fans	2
Fan Speed	2100 RPM
Radiator Material	Aluminum
Fan Dimensions	140mm x 25mm
Warranty	5 years
Compatibility	Intel 2011, 2066 and AMD AM4
Radiator Dimensions	140.0 mm
Fan Static Pressure	3.99 mm-H2O
Noise Level	37 dB(A)
