Corsair HX1000 User Manual

1 2
HX SERIES
™
HX SERIES
™
Product Specifications
HX .......................... 
HX .......................... 
HX ............................ 
HX ............................ 
Installation .................. 
SafetyandAgency
Approvals.................... 
Congratu
lations on the purchase of your new Corsair
HX Series High Performance ATX power supply.
Corsair HX Series enthusiast power supplies are optimized for silence,
with a custom fan design and Zero RPM Fan Mode. 80 PLUS Platinum
rated eciency ensures low-cost operation, and the fully modular
black cables allow for fast, neat builds. All Japanese 105°C capacitors
make it a great choice for high performance PCs where reliability
is essential.
Safety and protection
• Over-voltage protection (OVP)
Over-voltage protection for the 12V, 5V and 3.3V DC outputs
is required to comply with the ATX specification. OVP shuts
down the PSU in the event that the DC outputs exceed
a set level, determined by the PSU manufacturer. The minimum
voltage levels required for compliance are 13.4V for the
+12V rail(s), 5.74V for the +5V rail and 3.76V for the 3.3V rail.
• Over-current protection (OCP)
The HX Series features OCP on the 3.3V, 5V and 12V rails.
OCP ensures that the output of the DC voltage rails remains
within safe operating limits.
• Over-temperature protection (OTP)
OTP ensures that the PSU will shut down when the internal
temperature reaches a set point. This is usually as a result
of internal current overloading or a fan failure.
• Short-circuit protection (SCP)
A short-circuit is defined as any output impedance of less than
0.1 ohms. Amongst other things, SCP ensures that the PSU shuts
down should the 3.3V, 5V and 12V rails short to any other rail,
or to ground. It also ensures that no damage should occur to
the unit, or your PC’s components in the event of a short.

Corsair HX1000 Specifications

General

Total power	1000 W
Input current	10 A
AC input voltage	100 - 240 V
AC input frequency	47 - 63 Hz
Combined power (-12V)	9.6 W
Combined power (+3.3V)	150 W
Combined power (+5Vsb)	15 W
Max output current (+12V)	83.3 A
Max output current (-12V)	0.8 A
Power protection features	Over power, Over voltage, Overheating, Short circuit
Max output current (+3.3V)	25 A
Max output current (+5Vsb)	3 A
Cooling type	Active
Fan diameter	135 mm
Fan location	Top
Product color	Black
Number of fans	1 fan(s)
Purpose	PC
ATX version	2.4
EPS version	2.92
Noise level	- dB
Certification	FCC, ICES, CE, UL / CUL, CSA, C-Tick/RCM, TUV, CB, CU, KC Mark, WEEE, RoHS (China), REACH
80 PLUS certification	80 PLUS Platinum
Power supply unit (PSU) form factor	ATX
Sustainability certificates	RoHS
Manual	Yes
Package type	Box
Cabling type	Fully-Modular
SATA power cable length	450, 800 mm
Motherboard power connector	20+4 pin ATX
Floppy drive power connector	1
Floppy disk drive cable length	101 mm
Motherboard power cable length	610 mm
PCI Express power cable length	675 mm
Number of SATA power connectors	16
Peripheral (Molex) power cable length	450, 550, 650, 750 mm
Peripheral (Molex) power connectors (4-pin)	8

Weight and Dimensions

Depth	180 mm
Width	150 mm
Height	86 mm
Weight	1950 g
