Corsair HX1000 User Manual

7 8
HX SERIES
™
HX SERIES
™
HX850
Dimensions: 150mm (W) x 86mm (H) x 180mm (L)
Package contents
• Corsair HX Series power supply unit
• AC power cord
• DC Modular cable set
• DC Modular cable storage bag
• Cable ties
• Corsair case badge
• User manual
Corsair HX850 DC cable listing
Corsair HX850 power table
Corsair HX850 power supply eciency
Corsair HX850 power supply fan noise curve
Max Load Max Output
Model RPS0075 +3.3V 25A
150W
Part No. CP-9020138 / 75-002705 +5V 25A
AC input Rating 100 - 240V +12V 70.8A 850W
Input Current 12A - 6A -12V 0.8A 9.6W
Frequency 47 - 63Hz +5Vsb 3A 15W
Total Power: 850W
Qty Description Total Length
1
ATX Cable 24 Pin (20+4)
Connectors Per Cable
610mm
(± 10mm)
1
Total Connectors
1
2
EPS/ATX12V 8 Pin (4+4) Cable
Connectors Per Cable
650mm
(± 10mm)
1
Total Connectors
2
3
PCIe 8 Pin (6+2) Cable
Connectors Per Cable
775mm
(± 10mm)
2
Total Connectors
6
2
SATA Cable
Connectors Per Cable
800mm
(± 10mm)
4
Total Connectors
8
2
90° SATA Cable
Connectors Per Cable
800mm
(± 10mm)
4
Total Connectors
8
2
Peripheral Cable (4-Pin)
Connectors Per Cable
750mm
(± 10mm)
3
Total Connectors
6
1
Floppy Adapter (4-Pin)
Connectors Per Cable
101mm
(± 5mm)
1
Total Connectors
1
550mm 100mm 100mm 100mm
455mm 115mm 115mm 115mm
550mm 100mm 100mm 100mm
455mm 115mm 115mm 115mm
101mm
650mm
650mm
610mm
610mm
600mm
150mm
675mm
100mm
550mm 100mm 100mm
550mm 100mm 100mm
input 115Vac input 230Vac
% EFFICIENCY
Fan Noise (db)
Power Output (%)
24
22
20
18
16
14
12
10
8
6
4
2
0
0 10010 20 30 40 50 60 70 80 90
97
95
93
91
89
87
85
83
81
79
10010
5020
24
22
20
18
16
14
12
10
8
6
4
2
0
0 10010 20 30 40 50 60 70 80 90
97
95
93
91
89
87
85
83
81
79
10010
5020

Corsair HX1000 Specifications

General

Total power	1000 W
Input current	10 A
AC input voltage	100 - 240 V
AC input frequency	47 - 63 Hz
Combined power (-12V)	9.6 W
Combined power (+3.3V)	150 W
Combined power (+5Vsb)	15 W
Max output current (+12V)	83.3 A
Max output current (-12V)	0.8 A
Power protection features	Over power, Over voltage, Overheating, Short circuit
Max output current (+3.3V)	25 A
Max output current (+5Vsb)	3 A
Cooling type	Active
Fan diameter	135 mm
Fan location	Top
Product color	Black
Number of fans	1 fan(s)
Purpose	PC
ATX version	2.4
EPS version	2.92
Noise level	- dB
Certification	FCC, ICES, CE, UL / CUL, CSA, C-Tick/RCM, TUV, CB, CU, KC Mark, WEEE, RoHS (China), REACH
80 PLUS certification	80 PLUS Platinum
Power supply unit (PSU) form factor	ATX
Sustainability certificates	RoHS
Manual	Yes
Package type	Box
Cabling type	Fully-Modular
SATA power cable length	450, 800 mm
Motherboard power connector	20+4 pin ATX
Floppy drive power connector	1
Floppy disk drive cable length	101 mm
Motherboard power cable length	610 mm
PCI Express power cable length	675 mm
Number of SATA power connectors	16
Peripheral (Molex) power cable length	450, 550, 650, 750 mm
Peripheral (Molex) power connectors (4-pin)	8

Weight and Dimensions

Depth	180 mm
Width	150 mm
Height	86 mm
Weight	1950 g
