MOBILTEX® DATA LTD.
Calgary, Alberta
www.corTalk.com
TITLE: uDL2 Configuration and Operation Guide
DOCUMENT NO.:
UDL2-MAN-001
SHEET:
9 of 28
REV:
1.07
The following optional items are also available separately:
 CC Technologies Coupon Test Station Direct Interface Cable (Mobiltex P/N W164I0UDL03)
Figure 9 CC Technologies Coupon Test Station Direct Interface Cable
 USA/Canada AC USB Wall Charger (P11606UDL01)
Figure 10 USA/Canada AC USB Wall Charger
 DC USB Vehicle Charger (P11606UDL02)
Figure 11 DC USB Vehicle Charger
 Test Station Spacer Rings (Provide More Height Inside Standard Test Station)
H23510RMU01 (Black)
H23530RMU01 (Orange)
H23540RMU01 (Yellow)
H23550RMU01 (Green)
Figure 12 Test Station Spacer Rings
