CAUTION: HOOD MAY HAVE VERY SHARP EDGES; PLEASE WEAR
PROTECTIVE GLOVES WHENEVER IT IS NECESSARY TO REMOVE ANY
PARTS FOR INSTALLING, CLEANING OR SERVICING.
Step 1:
Place the range hood on the wall and mark
the position where you want to install. A height
of 25” to 35” is recommended for optimal
performance.
Step 2:
Step 3:
Find the exhaust pipe, attach it to the top air
outlet. Make sure it is connected tightly to the
air outlet.
8
INSTALLATION PROCEDURES
0.50"
9.1"
14.5"
A. Find the 2 mounting holes in the back of the
range hood. Mark their locations at the installation
location with a pencil or marker.
B. Drill 5/16 (8mm) hole at each of the marked
locations.
C. Insert anchors into each drilled hole. Firmly
screw them into place.
D. Hang your Range Hood into place by aligning the
anchors with the two mounting holes in the back of
the range hood.
