IMPORTANT:
Installation must be in compliance with all local codes and regulations.
In order to ensure adequate ventilation, provide a space of atleast 1.77" at the rear of the
cabinet. Installing the oven so that it rests on two strips of wood is preferable. If the oven
rests on a continuous, flat surface, there must be an cutout of at least 1 ¾” x 22”. (See
Figure 2)
The panels of the adjacent cabinets must be made of heat-resistant material. In particular, cabinets with
a veneer exterior must be assembled with glues which can withstand temperatures of up to 215°F.
In compliance with current safety standards, contact with the electrical parts of the oven must not be
possible once it has been installed.
To fasten the oven to the cabinet, open the door of the oven and attach it by inserting the 4 wooden
screws into the 4 holes located on the perimeter of the frame.
