Cosmo COS-244AGC User Manual

8 9
8
SPECIFICATIONS
Height 35.5” (900 mm)
Width 23.6” (600 mm)
Depth 23.6” (600 mm)
Depth with Backsplash 25.0” (635mm)
Product Weight 132 lbs.
Capacity 2.73 Cu. Ft.
35.5” (900 mm)
1.8’’ (46mm)
25.0” (635mm)
23.6” (600 mm)
Figure 1
9
PARTS AND FEATURES
PRODUCT PARTS & ACCESSORIES
CONTROL PANEL
Figure 2
Figure 3
c
a
b
d
e
Function Buttons
Clock and Timer
Burner Controller Oven Controller
a. Back Wall Plate (1)
b. Gas Cooktop Grate (1)
c. Control Panel (1)
d. Oven Door Handle (1)
e. Oven Window (1)
f. Oven Racks (2)
g. Grill Set: Basin & Anti-Splash (1)
h. Anti-Tip Bracket (1)
i. Anti-Slip Feet (4)
j. Screws (2)
k. Anchors (2)
h u j k
g
f
MIN
MAX
OFF
°F
325
300
350
400
450
Broil
OFF
°F
Conv
Fan
Light
MIN
MAX
OFF
MIN
MAX
OFF
MIN
MAX
OFF
MIN
MAX
OFF
LITE LITE LITE LITE
SPECIFICATIONS PARTS AND FEATURES
