21
Range Hood Mounting Bracket
1. Determine and mark the vertical centerline on the wall where the range
hood will be installed.
2. Select a mounting height between a minimum of 24" (61.0 cm) and a
suggested maximum of 36" (91.4 cm) above the cooktop/range to the
bottom of the range hood. Mark a horizontal line on the wall referencing
the bottom of the range hood.
NOTE:
• Make sure the chimney can reach the ceiling. For wall venting, it is
not necessary for the chimney to be in contact with the ceiling.
• For higher ceilings, chimney extensions are available to replace
the chimneys shipped with the range hood. To purchase, visit
www.cosmoappliances.com or reference the contact information
at the end of this manual.
WARNING EXCESSIVE WEIGHT HAZARD
• Use two or more people to move and install range hood.
• Failure to do so can result in back or other injury.
WALL BACK VIEW
Brackets Installation
To Next Page
