23
Chimney (Vent Cover) Support Brackets
WARNING EXCESSIVE WEIGHT HAZARD
• Use two or more people to move and install range hood.
• Failure to do so can result in back or other injury.
IMPORTANT:
• The inner (upper) chimney support bracket is slightly longer than the
outer (lower) chimney support bracket.
1. Using 2 or more people, hang range hood on mounting bracket through
the mounting slots on back of range hood.
2. Place both inner (upper) and outer (lower) chimneys onto hood. The inner
chimney must slide into the outer chimney.
NOTE:
• To help prevent scratches, lay paper or a kitchen towel over the
top edges of the outer (lower) chimney to protect the surface.
Inner (upper) chimney
Outer (lower) chimney
