28
7. (Optional) For models with screw holes on the range hood aligning with
the screw holes on both sides of the outer (lower) chimney at the bottom,
install (2) 3 x 10 mm screws.
Complete Installation
1. For ductless (recirculating) installations only: Install charcoal filters over
grille on blower housing. See the "Range Hood Care" section.
2. For models with oil tray included: Install the oil tray on the blower.
3. Install metal filters. See the "Range Hood Care" section.
4. Check the operation of the range hood blower and light. See the "Range
Hood Use" section.
Outer (lower) chimney
Inner (upper) chimney
