Cosmo COS-668AS750 - INSTALLATION PROCEDURES

10
Product Dimensions
631 SERIES
30" Model: COS-63175 / 63175S
36" Model: COS-63190 / 63190S
6 ³⁄₄"
(17.2 cm)
8 ¹⁄₄"
(20.9 cm)
30" Model: 29 ⁵⁄₁₆" (74.5 cm)
or
36" Model: 35 ¹⁄₄" (89.5 cm)
19 ¹¹⁄₁₆"
(50.0 cm)
1 ⁹⁄₁₆"
cm)(4.0
10 ³⁄₁₆"
(25.8 cm)
15 ¹⁄₂"
(39.3 cm)
Ducted (Vented):
25 ⁵⁄₈" (65.1 cm) min.
39 ⁷⁄₁₆" (100.1 cm) max.
Ductless (Recirculating):
29 ³⁄₄" (75.6 cm) min.
39 ⁷⁄₁₆" (100.1 cm) max.
