Costa Discovery - Installation and Assembly; Minimum Clearances; Mantel Clearances

4
PRODUCT DIMENSIONS
Model
Number
A
B
C
D
E
F
G
H
I
Discovery
50"
127cm
13"
33.2cm
21.2"
54cm
48.8"
124cm
12.5"
31.7cm
3.5"
9cm
48.6"
123.5cm
15"
38.1cm
7.7"
19.5cm
Discovery XL
60"
152.4cm
13"
33.2cm
21.2"
54cm
58.8"
149.4cm
12.5"
31.7cm
3.5"
9cm
58.6"
148.9cm
15"
38.1cm
7.7"
19.5cm
Installation and Assembly
Your appliance is a recessed and/or mantel installed appliance. Select a suitable location that is
not susceptible to moisture and is away from drapes, furniture and high traffic areas.
NOTE: Follow all National and local electrical codes.
MINIMUM CLEARANCE TO COMBUSTIBLES
Measurements are taken from the glass front.
Bottom
Sides
Back
0"
0"
0"
Top
Top
11.8" (300mm) to mantel
11.8" (300mm) to ceiling
MINIMUM MANTEL CLEARANCES
WARNING
WHEN USING PAINT OR LACQUER TO FINISH THE MANTEL, THE PAINT OR LACQUER MUST BE
HEAT RESISTANT TO PREVENT DISCOLOURATION.
