3-1-6. Status：Display Power & Fault Status
Green LED LED Signal Status
Solid Power OK
Blink (Slow)
- - - - - - -
Power Saving
Red LED LED Signal Status
Blink (Fast)
- - - - - - - - - - - -
OVP
Blink (Slow)
- - - - - - -
UVP
Blink
(Intermittently)
. . . . . . . .
OTP
Solid OLP
3-1-7. Power Saving Mode: Power Saving Mode is adjustable and
set by the Dip Switches, S1, S2 and S3 on front panel.
Example: With the watt setting at 15W, a 15W↑ load will
bring the inverter to operate normally, a 15W↓ load, the
Power saving mode presents.
SK700
SK1000
SK1500
SK2000
SK3000
S1 S2 S3
DISABLE DISABLE DISABLE OFF OFF OFF
15W 20W 40W ON OFF OFF
30W 40W 80W OFF ON OFF
40W 50W 100W ON ON OFF
56W 60W 120W OFF OFF ON
70W 80W 160W ON OFF ON
84W 90W 180W OFF ON ON
100W 110W 220W ON ON ON
