Coxo CX235 - Mounting and Removing Bur (20:1 Reduction); Locking Pin Bur Mounting (20:1); Push Button Bur Mounting (20:1)

Insert bur
Switch out the rightside
Locking pin
Open the latch chuck,insert the bur,be sure the quadrate part of the bur
aline the proper part in the cartrdge then turn the latch chuck back.
When remove the bur,open the latch chuck then take out the bur.
Mounting and Removing Bur
Insert bur
Switch out the rightside
NOTE:
1-Do not connect or disconnect the handpiece until the drive motor has
completely stopped.
2-After the file is locked in place, lightly pull out the bur to make sure
the bur is locked.
Fig.11.2
Fig.11.1
push button
Fig.11.3
20:1 reduction
