Use the attached wrench to remove the cap[Fig.2.2].
Use the bur to push out the cartidge.
Insert the new cartridge into handpiece head,being sure the small raised
part aligns the groove inside the front of the head,to insure proper fit.
Loosen the small screw on the curving part ,move the head cover and remove
the transmission gear[Fig.2.1].
Fig.2.2 Fig.2.4Fig.2.3
1
:
1
Cartridge Replacement
•Inner channel contra angle low speed handpiece ;
•Burs:for CA burs Φ2.35;
•Max.speed of contra angle:40000rpm
Inner channel1:1
4
Fig.2.1
