Coxo CX235 - Special Head Movement Parameters

Fig. 1.6
7
2.Special head movement technical parameters
Model Rotate head BUR
CX235CH-10 90° reciprocating for CA burs Φ2.35/prophylaxis brush
CX235CH-11 Up and down movement for CA burs Φ2.35/the crevices knife
CX235CH-12 60° reciprocating for use files
Fig. 1.5
90° reciprocating rotate head
90°
Up and down mov ement
60° reciprocating rotate head
60°
Internal spray nozzle
Irrigation tube
wate r outlet
wate r outlet
Inte rnal spra y nozzle
Irri gation tu be
Fig. 1.8
Fig. 1.7
Fig. 1.9
CX235CH-9 360° reciprocating forCA burs Φ2.35/implant files
CX235CH-14 360° reciprocating forCA burs Φ2.35/implant files
EXTERNAL CHANNEL
