Recommended type of
manual press.
FLEX HEAD ASSEMBLY INSTRUCTIONS
Concrete Polishing Solutions- G-290 Operator’s Manual
24/7 Technical Support- Toll Free 1-877-472-8200
27
Step 6
Continue to apply downward press pressure to the assembly, use your hands
to push the Polycord holder down on the main Mounting Plate studs. Do this
until the outer Polycord holder can be placed on the studs far enough to place
a at washer and a loosely t nut.
Do not over apply ram pressure as to completely bottom out the
spring.
Tighten all the nuts to snug with a 7/16” wrench.
Remove ram pressure and remove assembly.
Note: Polycord is just
touching main mounting plate
enough to apply outer
polycord holder and leave
enough room to place
at washer and locking nut.
To Next Page
