The assembly with at washers
and locking nuts in place prior to
relieving ram pressure.
Note: For illustration only.
Nuts have been properly
torqued in this photo.
FLEX HEAD ASSEMBLY INSTRUCTIONS
Concrete Polishing Solutions- G-290 Operator’s Manual
24/7 Technical Support- Toll Free 1-877-472-8200
28
Using a criss-cross method torque all
nuts to 6 foot pounds.
Final torque of lock nuts.
Final assembly as viewed from the main
mounting plate side showing proper
alignment of holes.
