Craftex CX101 - Page 27

27
1 BODY
2 QUICK HANDLE BAR
3 T TYPE WASHER
4 UPPER WHEEL BRACKET
5 SCREW
6A UPPER WHEEL SHAFT 17MM
7 BEARING
7A BEARING
8A UPPER WHEEL - Cast Iron
9 WHEEL PROTECTOR(TIRE)
10 C-RING
10A C-RING
11 RETAINER NUT
12 BLADE 133"
13 HINGE PIN
14 UPPER GUARD
15 LOWER GUARD
16 CAP SCREW 1/4"*3/8"
17 LOCK WASHER 1/4"
18 HEX NUT 3/4"(L.H.)
19A LOWER WHEEL -CAST IRON
21A LOWER WHEEL SHAFT
22 LOCKNUT 3/8"
23A BEARING
23B BEARING
24 KEY 5MM
25 NUT
26A SPRING WASHER
27 CORD
30A NUT 5/8
31 NUT
32 POINTER
33 SPRING
34 STRAIN RELIEF
35 HEX NUT 5/16"
36 KNOB 5/16*2"
37 POWER CORD
38 GUARD LOCKING KNOB
39 SCREW
40 CORD
41 PIN
42 HEX NUT 3/8"
43 SCREW
44 BEARING COVER
45 NUT
46 SCREW
47 ADJUSTING SCREW
48A BEARING BASE
49 NUT
50 V-BELT A41
51 SET SCREW 1/4"*1/4"
52A WHEEL PULLEY
53 IDLER PULLEY
54 MOTOR PULLEY
55 V-BELT A30
56 C-RING
57 SHAFT
58 WASHER
59 MOTOR
60 FLAT WASHER 3/8"
62 HEX BOLT 3/8"*1 1/4"
63 SWITCH COVER
63 TENSION LABLE
64 SCREWM4*6
65 PHILLIPS HEAD SCREW M3*18
66 SCREW
67 SCREW
68 PHILLIPS HEAD SCREW 3/16"*1/2"
69 CONTROLLER COVER PLATE
70 HEX NUT 3/16"
71 MOTOR INVERTER SWITCH
72 SPEED DIAL
73 SWITCH W/LARGE STOP
74 INVERTER RHYMEBUS RMG-5 1HP
75 HEX BOLT 5/16"*3/4"
76 HEX NUT 5/16"
77 BRUSH BASE
78 SCREW
79 BRUSH
80 HEX BOLT 1/4"*3/4"
CX101 BODY PARTS LIST
REF# DESCRIPTION REF# DESCRIPTION
