11
ON/OFF SWITCH
The CX509 features an ON/OFF switch
with a removable key. The key can be
removed to prevent the sander from
unauthorized use.
Figure-7 ON/ OFF switch with removable
key
VARIABLE SPEED
The CX509 features a variable speed knob
which allows you to increase the feed rate
from 2-12 FPM. The correct speed to use
depends on the type of wood being used.
A slower feed rate will provide a smoother
result but has the risk of burning the wood
while a faster feed rate removes the
material faster but has the risk of
overloading the motor or damaging the
sanding paper.
We recommend to run a few test runs with
different speeds before sanding your actual
work-piece.
TO ADJUST THE FEED BELT SPEED:
Turn ON the feed belt.
Rotate the variable speed knob to increase
or decrease the feed speed.
Figure-8 Variable speed knob
WARNING!
Do not adjust the variable speed knob
while the conveyor motor is OFF. Failure
to do so could result in damaging the V-
belt and adjusting mechanism.
WARNING!
Do not adjust the variable speed knob
while the conveyor motor is OFF. Failure
to do so could result in damaging the V-
belt and adjusting mechanism.
