page 3
1. Unpacking Your Fan.
Carefully open the packaging. Remove items from Styrofoam
inserts. Remove motor housing and place on carpet or
Styrofoam to avoid damage to nish. Do not discard fan carton
or Styrofoam inserts should this fan need to be returned for
repairs.
Check against parts inventory that all parts have been
included.
2. Parts Inventory.
IMPORTANT REMINDER: You must
use the parts provided with this fan for
proper installation and safety.
a. canopy. 1 piece
b. hanging bracket. 1 piece
c. downrod and hanging ball. 1 piece
d. motor housing. 1 piece
e. switch housing plate. 1 piece
f. switch housing cap. 1 piece
g. yoke cover. 1 piece
h. blade plate. 6 pieces
i. blade. 6 pieces
j. canopy cover (in hardware pack). 1 piece
k. wall control. 2 pieces
l. remote control cover. 1 piece
m. plate. 1 piece
n. faceplate. 3 pieces
o. hardware packs
a
f
g
i
j
b
c
o
e
d
k
l
m
h
n
OFF ON
I
II
IV
VI
III
V
