2. Parts Inventory.
a. hanging bracket. 1 piece
b. canopy. 1 piece
c. downrod and hanging ball. 1 piece
d. yoke cover. 1 piece
e. motor housing. 1 piece
f. canopy cover (in hardware pack). 1 piece
g. fitter plate. 1 piece
h. wall control and plate. 2 pieces
i. LED light kit.1 piece
j. glass shade. 1 piece
k. blade arm. 5 pieces
l. blade. 5 pieces
m. hardware packs
page 2
1. Unpacking Your Fan.
Carefully open the packaging. Remove items
from Styrofoam inserts. Remove motor housing
and place on carpet or Styrofoam to avoid
damage to finish. Do not discard fan carton or
Styrofoam inserts should this fan need to be
returned for repairs.
Check against parts inventory that all parts have
been included.
IMPORTANT REMINDER: You must
use the parts provided with this fan for
proper installation and safety.
w/wall
control
dabc
k
l
m
h
e
f
i
j
g
