8
SPECIFICATIONS
NOTE: Accuracy specifications consist of two elements:
• (% reading) – This is the accuracy of the measurement circuit.
• (+ digits) – This is the accuracy of the analog to digital converter.
NOTE: Accuracy is stated at 64
o
F to 82
o
F (18
o
C to 28
o
C) and less than
75% RH ambient MultiMeter conditions.
Diode Test Test current of approximately 1mA, open
circuit voltage 2.8V DC typical
Continuity Check Audible signal will sound if the resistance is
less than approximately 70!, open circuit
voltage 2.8V DC typical
Input Impedance 10M! (VDC and VAC)
Display 2000 count LCD
Overrange indication “1” is displayed
Polarity Automatic (no indication for positive polarity);
Minus (-) sign for negative polarity.
Measurement Rate 0.4 seconds, nominal
Low Battery Indication “ ” is displayed if battery voltage drops
below operating voltage
Battery Requires one 9V NEDA 1604 or 6F22 battery
(sold separately)
Fuses mA range, 200mA/250V fast blow
10A range, 10A/250V fast blow
