9
SPECIFICATIONS
Operating Temperature 32
o
F to 104
o
F (0
o
C to 40
o
C)
Storage Temperature 10
o
F to 122
o
F (-10
o
C to 50
o
C)
Relative Humidity <70% operating
Operating Altitude 2000 meters (7000ft.) maximum.
Operating Humidity Max 70% up to 87ºF (31ºC) decreasing linearly
to 50% at 122ºF (50ºC)
Weight 12.34oz. (350g).
Size 7.52” x 3.23” x 1.42” (191mm x 82mm x 36mm)
Safety For indoor use and in accordance with
Overvoltage Category II, Pollution Degree 2.
Category II includes local level, appliance,
portable equipment, etc., with transient
overvoltages less than Overvoltage Category
III.
BATTERY INSTALLATION
WARNING: To avoid electric shock, disconnect the test leads from any
source of voltage before removing the battery door.
1. Disconnect the test leads from the meter.
2. Open the battery door by lifting the rear stand and removing the two
screws using a Phillips head screwdriver.
3. Insert the battery into battery holder, observing the correct polarity.
4. Put the battery door back in place. Secure with the two screws.
WARNING: To avoid electric shock, do not operate the meter until the
battery door is in place and fastened securely.
NOTE: If your meter does not work properly, check the fuses and battery to
make sure that they are still good and that they are properly
inserted.
