Craftsman C459-36310 - Spark Plug Service

16
SERVICE AND MAINTENANCE
Outer Engine
Shroud
Recoil Starter
Housing
Figure 18
Inner Shroud
Foam Filter
Cap
Figure 19
6. Snapthecarboncanisterfilterassemblybackintoplaceundertheinner
engineshroud.SeeFigure20inset.
IMPORTANT: Besuretheanglednipplepointsupwardsintotheshroudto
avoidinterferencewiththeautochokelinkage.
Angled Nipple
Figure 20
7. Placetheinnerengineshroudbackontotheengine.Fastentherecoilstarter
housingbackdownandreattachtheouterengineshroud.
Spark Plug Service
WARNING
DO NOT check for spark with spark plug removed. DO NOT crank engine
with spark plug removed.
1. Removethesparkplugbootanduseasparkplugwrenchtoremovethe
plug.SeeFigure21.
Spark Plug
Spark Plug Boot
Figure 21
WARNING
If the engine has been running, the muffler will be very hot. Be careful not
to touch the muffler.
