Craftsman C459-36310 - Attaching the Grass Catcher

9
ASSEMBLY
3. Followthestepsbelowtocompletehandleassembly:
4. Pullupwardonthehandleuntilholesinlowerhandle(showninFigure3
deckcutaway)lineupwithholesinhandlebracket.SeeFigure4.
A
B
B
Figure 4
NOTE: Whenpullingupwardonhandle,makesuretonotpullhandleallthe
wayout.
a. InserttheT-boltsremovedinstepearlierthroughthehandle
bracketsandlowerhandleandtightensecurelytosecurethehandle
inplace.SeeFigure4.
b. Reattachwingnutsandcarriageboltsremovedearlierintolower
holesofhandleasshowninFigure5.
C
C
Figure 5
4. Theropeguideisattachedtotherightsideoftheupperhandle.Loosenthe
wingknobwhichsecurestheropeguide.RefertoFigure6.
a. Holdbladecontrolagainstupperhandle.
b. Slowlypullstarterropehandlefromengineandslipstarterropeinto
theropeguide.SeeFigure6.
c. Tightenropeguidewingknob.
d. Usecabletiestosecurebladecontrolcabletolowerhandle.
A
B
C
D
Figure 6
Attaching the Grass Catcher
1. Followstepsbelowtoassemblethegrasscatcher.Makecertainbagisturned
rightsideoutbeforeassembling(warninglabelwillbeontheoutside).
a. Placebagoverframesothatitsblackplasticsideisatthebottom.
b. Slipplasticchannelofgrassbagoverhooksontheframe.SeeFigure7.
b
a
Figure 7
