Engine Model 5X65RU/
Modèle du moteur 5X65RU
PARTS LIST/PIÈCES DÉTACHÉES
31
Ref.
No./
f.
Part No./
No. de
pièce
Description Désignation
28 951-14402 Brake Assembly Frein
36 712-04219 Brake Arm Nut Écrou
38 712-04209 Ground Switch Nuts M4 Écrous M4
43 750-05384 Brake Spacer Entretoise du frein
44 710-04980 Bolt M6×35 Af Base/Brake/Dipstick Boulon M6 x 35
45 710-04918 Bolt M6×30 Ignition Coil Boulon M6 x 20, bobine
46 951-11622 Flexible Clamp, Ignition Coil Collier, bobine
47 951-14403 Ignition Coil Assembly Bobine
48 710-04916 Bolt M6×14 Boulon M6 x 30
49 951-14404 Breather Cover Plate Plaque
50 951-14405 Breather Gasket Joint
51 951-11596 Upper Crankshaft Seal Joint de vilebrequin
52 951-11730 Breather Screen Tamis
53 732-04718 Breather Valve Spring Ressort
54 951-11614 Breather Valve Soupape
64 710-04915 Bolt M6X12 Multi-Purpose Boulon M6 x 12
71 951-14408 Choke Linkage Tringlerie
72 951-14409 Throttle Linkage Spring Ressort
73 951-14410 Throttle Linkage Tringlerie
74 951-14 411 Governor Spring Ressort de reniard
75 951-14412 Governor Arm Assembly Reniard
79 951-14413 Component Bracket Support
80 951-14414 Air Vane Bracket Support
81 951-11529 Air Vane Girouette d'air
82 714-04074 Governor Arm Shaft Cotter Pin Goupille fendue
83 951-11574 Governor Seal Joint
84 951-14416 Governor Arm Shaft Boulon
85 951-11520 Breather Hose Assembly Écrou M6
86 726-04101 Breather Hose Clamp Collier
88 951-14415 Crankcase Cover Gasket Joint
89 951-14447 Short Block Bloc moteur embiellé
(Incl. 48-54,82-84,88-92,95,97-100, (Comprend les nos. 48-54,82-84,88-92,95,97-100,
110-116,126,132,133,149,152,156, 110-116,126,132,133,149,152,156,
157,159-161,166-169,172) 157,159-161,166-169,172)
90 951-11369 Main Bearing Roulement principle
161 951-14433 Piston Ring Set Piston de segment
166 951-11603 Piston Pin Snap Ring Axe de piston pour anneau élastique
167 951-14434 Piston Piston
168 951-14435 Piston Pin Axe de piston
169 951-14436 Connecting Rod Assembly Ensemble de bielle
172 710-05115 Connecting Rod Bolt Boulon
176 951-14443 Gasket Kit - Complete Trousse - joint complet
(Incl.50,51,83,88,95,113,116,126, (Comprend les nos. 50,51,83,88,95,113,116,126,
128,131-133,149,152,156) 128,131-133,149,152,156)
177 951-14444 Gasket Kit -External Trousse - joint complet
(Incl. 50,95,113,126,128, (Comprend les nos. 50,95,113,126,128,
131-133,149,152) 131-133,149,152)
178 952Z5X65RU Engine Complete Moteur complet
