11
OPERATION
Figure 6
Meets ANSI Safety Standards
Craftsman Tractors conform to the safety standard of the American National Standards Institute (ANSI).
A Parking Brake Lever F PTO Lever (Blade Engage)
B Throttle/choke Control Lever G Cup Holder
C Ignition Switch Module H Shift Lever
D Auto-drive Pedal I Seat Adjustment Lever
E Deck Lift Lever J Brake Pedal
NOTE: Any reference in this manual to the RIGHT or LEFT side of the tractor is observed from operator’s seat
position facing forward towards the front of tractor.
A
B
C
J
D
E
G
F
H
I
