Craftsman C459.60310 - Parts List (Engine)

29
PARTS LIST
Craftsman Model C459.60310
Ref.
No.
Part No. Description
1 925-1649 Bulb Socket
2 683-04619A-4044 Hood Assembly
3 710-04484 Screw, 5/16-18 x .750
4 710-0599 Hex Washer Screw, 1/4-20 x .500
5 712- 0292 Tin Clip Nut, 1/4-20
6 710-0751 Hex Screw, 1/4-20 x .620
7 710-05108 Screw, 1/4 x .750
8 712- 04064 Nut, Hex Flange Insert Lock, 1/4-20
9 931-07668 Grill
10 731- 07458 Headlight Lens, RH
11 731- 07459 Headlight Lens, LH
12 731- 07460A Dash Collar
13 731- 07711A Hood Scoop, LH
14 731-07712A Hood Scoop, RH
15 735-0271A Bumper
16 738- 04091A Shoulder Screw, 5/16-18
17 783-05327B-0637 Left Support Pivot Bracket
18 783-05328A-0637 Right Support Pivot Bracket
19 783-06598-4044 Lower Grill
20 783-06610-0637 Lower Grill Bracket
21 731-09253 Shift Lever
22 710-05070 Self-Tap Screw, 1/4-20
23 710-3144 Hex Head Screw, 3/8-16
24 731-07966A Control Index
25 712-04065 Nut, Hex Flange Insert Lock, 3/8-16
26 732-04877 Compression Spring
27 783-06823 Speed Latch Support Tab
28 750-04465C Flange Spacer
29 783-06991-0637 Speed latch Bracket No RMC
30 710-0604A Self-Tap Screw, 5/16-18
Ref.
No.
Part No. Description
31 741-0587 Steering Column Bearing
32 712- 04063 Nut, Hex Flange Lock, 5/16-18
33 783-06785A-0637 Steering Support Bracket
34 783-06811-0637 Dash
35 747-05371 Fuel Tank Support Rod
36 710-3025 Hex Head Screw, 5/16-18
37 747- 05398 Control Rod
38 951-04304 Fuel Tank
39 951-12179A Fuel Cap
40 783-07083-0637 Gas Tank Support Bracket
41 731-05265 Choke Plug
42 746-04367 Throttle/Choke Assembly
43 925-04659 Key Switch Module
44 625-04124 Key Assembly
45 725-0157 Cable Tie
46 925-0963 Headlight Bulb
47 726-04072A Ratchet Clip, .250 x .500
48 936-0463 Flat Washer, .25 x .630 x .0515
49 735-04081 Rubber Grommet
50 751-12118 Fuel Rollover Valve
51 751-12089 Vent Hose
52 710-1652 Hex Washer Screw, 1/4-20 x .625
53 931-08542A Upper Dash
54 710-05237 Hex Flange Bolt
55 912- 0414 Top Lock Weldnut
56 736-3006 Lock Washer
57 910-0224 Screw, #10
— 777X44366 Headlight Reector LH
(Not Shown)
— 777X44365 Headlight Reector RH (Not Shown)
