31
PARTS LIST
Craftsman Model C459.60310
Ref.
No.
Part No. Description
1 683-04155A-0637 Shaft, Lift
2 712-04065 Nut, Hex Flange Insert Lock, 3/8-16
3 714-04040 Bow-Tie Pin, 91, RH
4 716-0106A E-ring, .625 Shaft
5 720-0311 Grip, Handle
6 732-04225 Spring, Lift Handle Torsion
7 738-04130 Bolt, Shoulder, .625 x .175:3/8-16
8 941-0225 Bearing, Hex Flange,
9 747-05296 Handle, Lift
10 747-04393 Lift Rod, 13.68
11 783-04494C-0637 Arm, Deck Lift RH
783-04711C-0637 Arm, Deck Lift LH
12 647-04096A-0637 PTO Handle Assembly
13 710-3157A Screw, Hx. Hd., 7/16-20 x 3.25
14 710-0599 Screw, Hd. Tapp, 1/4-20 x .5
15 714-04040 Click Pin
16 720-04049A Handle Grip
17 732-04276A PTO Spring, Extension
18 936-0171 Washer, Flat, 7/16
19 736-0322 Washer, Flat, .450 x .250 x .164
20 738-04237A Shoulder Screw, #10-32 x .500
21 741-04119A PTO Bearing
22 946-04173E Deck Engagement Cable
23 725-04439 12v. Solenoid
Ref.
No.
Part No. Description
24 756-04196A Engagement Pulley
25 747-04857 Belt Keeper Rod Assembly
26 710-04484 Screw, Hd. Tapp, 5/16-18 x .75
27 683-04195-0637 Support Bracket Assembly
28 683-04649A-0637 Rider Frame Assembly
29 710-0134 Carriage Screw, 1/4-20 x .62
30 710-3008 Screw, Hx. Hd., 5/16-18 x .75
31 712-04063 Nut, Hex Flange Insert Lock, 5/16-18
32 712-04064 Nut, Hex Flange Insert Lock, 1/4-20
33 912-0429 Hexlock Nut, 5/16-18
34 732-04035 Spring, Compress., 1.28 x 3.125
35 736-0173 Flat Washer, .28 x .74 x .063
36 783-04548D-0637 Seat Bracket Frame
37 783-04637-0637 Running Board Bracket
38 783-04753-0637 Frame Support Bracket
39 783-04869A-0637 Battery Bracket
40 783-05389A-0637 Frame Brace Bracket
41 925-1707D Battery
42 738-1132 Screw, Shoulder, .250 x .150
43 712-0271 Nut, Sems, 1/4-20
44 683-04448-0637 Battery Rod
45 725-04363 Interlock Switch
46 936-0300 Flat Washer, .406 x .875 x .059
