33
PARTS LIST
Craftsman Model C459.60310
Ref.
No.
Part No. Description
1 617-04094 Gear Assembly, Steering
2 710-0643 Screw, 5/16-18, 1.00, Gr5, Lock
3 710-1309 Screw, Mach, 5/16-18, 0.750
4 710-0514 Hex Head Screw, 3/8-16 x 1.00
5 710-3180 Screw, 5/16-18, 1.75, Gr5
6 912-0214 Nut, Jam Lock, 3/8-24
7 912-0240 Nut, Jam, 7/16-20, Gr2
8 712-04063 Nut, Flange Lock, 5/16-18, Grf
9 712-04065 Nut, Flange Lock, 3/8-16, Grf
10 923-0448A Ball Joint, 7/16-20, Lock
11 736-0242 Washer, Bell, .340 x .872 x .060
12 931-0484A Hub Cap
13 738-04141 Shoulder Screw, 5/16-18
14 738-04162C Shoulder Spacer, .8840 x .190
15 738-0919A Steering Shaft, 5/8 Spline x 21.86
16 941-04124 Bearing, Flange, Hex 5/8
17 747-05385 Drag Link, Steering
18 948-0389 Cap, 1.25 x .16
19 748-04278-0637 Steering, Block
20 748-04068 Spacer, .710 ID x .125 OD x .56
Ref.
No.
Part No. Description
21 683-0128B-0637 Pivot Bar Axle Assembly
22 710-04484 Screw, 5/16-18, 0.750
23 712-04065 Nut, Flange Lock, 3/8-16, GrF
24 714-0162 Pin, Cotter, 5/32, 1.25
25 914-0474 Pin, Cotter, 1/8 x 0.75
26 736-0341B Push Cap, 3/4
27 731-04057A Axle Cap
28 736-04228A Washer, Flat, .781 x 1.59
29 738-04128 Screw, Shlder, .500 x 2.380, 3/8-16
30 741-0660A Flange Bearing
31 747-04299A Tie Rod
32 783-05326B-0637 Pivot Bar Bracket
33 938-04007A-0637 Axle Assembly LH
34 638-04008P Axle Assembly RH
35 631-04028 Steering Wheel, Standard Grip
36 731-06825 Cap, Steering Wheel (Crafts. logo)
37 634-05053-0961 Wheel Assembly
38 634-05066-4042 Rim
39 734-04240A-0901 Tire, 15 x 6 x 6 Rd. Shoulder
40 934-0255 Valve Stem
