39
PARTS LIST
Craftsman Model C459.60310
Ref. Part No. Description
1 918-04566 Dr Assembly, Autodrive Lt-5
2 683-04606 Auto-drive Bracket Assembly
3 753-06662 Idler Bracket Assembly
4 710 -1260A Tap Screw, 5/16-18 x 0.750
5 712- 04065 Flange Lock Nut, 3/8-16
6 738-0322A Shoulder Screw, .625 x .217
7 956 -04015A Pulley Assembly, Var. Spd. 4.75 Od
8 683-04522 Belt Keeper Assembly
9 683-04612-0637 Variable Bracket Assembly
10 710-0627 Hex Screw 5/16-24 .750
11 710-0778 Tap Screw, 1/4-20 1.500
12 718-04261 Bearing Cup
13 736-0362 Wash, Flat .330 X 1.25 X .06
14 941-0600 Ball Bearing, 17 x 40 x 12.6203
15 647-04266 Lvr Assembly, Shft
16 647-04201A-0637 Ped Assembly, Drive, Autodrive
17 647-04203A-0637 Ped Assembly, Cont, Autodrive
18 683-04736 Bracket Assembly, Pedal, Autodrive
19 710-0227 Screw, Ab, #8-18, 0.500
20 710-04484 Screw, Tt, 5/16-18, .750
21 710-0604A Screw, Tt, 5/16-18, 0.625
22 710-0809 Screw, Tt, 1/4-20, 1.250
23 710-0859 Hex Hd. Screw, 3/8-16, 2.50
24 710-1007 Screw, Ttsems, 3/8-16, 1.500
25 710 -1266 Hex Hd. Screw, 5/16-18, 3.50
26 710-1026 Screw, Tt, 1/4-20, 1.75
27 710-1858A Screw, Tt, 3/8-16 x 1.75
28 710-3008 Hex Hd. Screw, 5/16-18, .75
29 912- 0240 Nut, Jam, 7/16-20
30 712- 0241 Nut, Hex, 3/8-24
31 712- 04063 Nut, Flange Lock Nut, 5/16-18
32 912-3000 Nut, Flange Lock Nut, 3/8-16
33 712-0700 Nut, Flg, 9/16-18
34
736-3040
Wash, Flat, .406 x 1.920 x .060
35 914-0209 Pin, Cotter Int- .125 Dia
36 714-04040 Pin, Cot, Bow-Tie 72
37 718-04407 Hub, Pulley, 5/8 Spline
38 720-04028 Knob, Shft
39 923-3018 Ball, Joint
40 725-0157 Cable, Tie, 3/16 X .05 X 7.4
41 725-1644 Switch, Spring, Short
42 726-0214 Cap, Push 5/8
43 926-0320 Plate, Insulator Nut
Ref. Part No. Description
44 731-04602 Sleeve, .758 X .821 X 3.3125
45 731-04604 Sleeve, .758 X .821 X 2.4375
46 731-06330 Plug, Deck Hole, 7/8
47 731-06894 Shift Plate Bearing
48 732-04488 Spring, Ext, .38 Od X 3.25 Lg
49 732- 04612 Spring, Extn, .70 Dia X 12.00 Lg
50 732-04616B Spring, Extn, .97 Od X 6.18 Lg
51 732-04764 Spring, Extn, .56 X 12.05 x .068
52 732-0716D Spring, Extn, .59 Od X 4.00 Lg
53 735-0239 Pad, Foot, 4.0 Long
54 735-04272 Pad, Cont
55 936-0169 Wash, Lock, 3/8, Regular Duty
56 936-0185 Wash, Flat, .375 X .738 X .063
57 738-0372B Spacer, Shoulder, 1.00 X .38 X .38
58 738-04091A Screw, Shoulder, .43x.29, Tt, 5/16-18
59 741- 0495 Bearing, Flg, .630 Idx .695 Od X .60
60 734-1730-0901 Tire, 20 x 8 x 8 Sq. Sh.
61 747-05188 Rod, Brake, Lt-5 Trans
62 747-05243 Rod, Shift, Lt-5 Stretch 46”
63 747-05596 Rod, Adj, Idlr, 3/8
64 747-05415 Rod, Trans, Footpedal Bypass
65 948-0334 Spacer, T-Axle .68
66 750-04456 Spacer, .260 X .372 X 1.420 Lg
67 750-0566A Spacer, .260 X .375 X 1.030 Lg
68 954-04208 Belt, V Typ, 5l X 40.9 Lg Poly
69 954-0467A Belt, V Typ, 5l, 90.80, Poly
70 956-04002 Pulley, Idlr, Flat 7.25 Od
71 756-04224 Pulley, Idlr, Flat 2.75 Od
72 756-04325 Pulley, Idlr, V-Type X 3.06
73 783-04536B-0637 Bracket, Ped, Support Lt-5
74 783-04595A Bracket, Shft, Adj
75 710-05339 Sems Screw, 5/16-24 x .750
76 783-06562A-0637 Bracket, Ped, Frame Rh
77 783-06592A Bracket, Idlr, Dbl Autodrive
78 783- 06641A Bracket, Supt, Pedal Stap
79 783-06769 Bracket, Idlr, Center Dbl
80 783-06807A-0637 Pedal Stop Plate
81 725-04363 Interlock Switch
82 17962 Switch Plate
83 634-0104-0961 Wheel Assembly, 20 x 8 x 8 Sq. Sh.
84 934-0255 Valve Stem
85 634-04369-4042 Rim Assembly
—
925-04567G Wiring Harness (Not Shown)
