ASSEMBLY
TOOLS REQUIRED FOR ASSEMBLY
1 - Knife
2 - 1/2"wrenches (or adjustablewrenches)
2 - 9/16" wrenches (or adjustable wrenches)
2 - 3/4"wrenches (or adjustablewrenches)
1 - 3/8" wrenche (or adjustablewrench)
1 - Pair pliers or screw driver (to spread cotter pin)
CONTENTS OF SHIPPING CARTON
1- Snow Slower
1- Container of Fuel Stabilizer
1- Snow Chute Assembly
1- Crank Assembly
1- Parts Bag
HOW TO MEASURE SCREW SIZE
_ DIAMETER
_hb WARNING: Always wear safety glasses or
eye
shields while assembling snow blower.
PARTS BAGS CONTENTS:
1- Shifter Knob
OI
OI
* 2 - Wrenches
* 2-1/4-20 x 1.75
©@
* 2-Spacer
* 2-1/4-20
Hex nut
*Non Assembly parts are found in toolbox located on top of belt cover.
7
To Next Page
