Operator's Manual
Model No. 486.245071
®
PRINTED IN U.S.A. FORM NO. 40509 (09/19/07)
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.
www.sears.com/craftsman
CAUTION:
Before using this product, read
this manual and follow all Safety
Rules and Operating Instructions.
Safety•
Assembly•
Operation•
Maintenance•
Parts•
STOP
DO NOT RETURN TO STORE
For Missing Parts or Assembly
Questions Call 1-866-576-8388
TM

Questions and Answers

  • G
    Glenn BrownJul 30, 2025
    Why won't my Craftsman Yard Vacuum engine start?
    • R
      Robert MaxwellJul 30, 2025
      If your Craftsman Yard Vacuum engine won't start, here are a few potential causes and solutions: * The spark plug wire might be disconnected. Connect the wire to the spark plug. * The safety switch may not be contacted. Correctly install the hose adapter nozzle. * The fuel tank could be empty or contain stale fuel. Fill the tank with clean, fresh fuel. * The fuel shut-off valve might be closed. Open the fuel shut-off valve. * The spark plug could be faulty. Clean, adjust the gap, or replace the spark plug.
  • K
    Katie WoodsAug 5, 2025
    What to do if my Craftsman MONSTER 486.245071 is losing power?
    • J
      James DixonAug 5, 2025
      If your Craftsman Yard Vacuum is losing power or operating erratically, consider these potential issues: * A loose spark plug wire. Connect and tighten the spark plug wire. * The unit running on CHOKE. Move the choke lever to the OFF position. * A blocked fuel line or stale fuel. Clean the fuel line and fill the tank with clean, fresh gasoline. * Water or dirt in the fuel system. Disconnect the fuel line at the carburetor to drain the fuel tank and refill with fresh fuel. * The carburetor out of adjustment. Adjust the carburetor. * A dirty air cleaner. Service the air cleaner.
  • T
    Tyler ThomasAug 10, 2025
    Why is my Craftsman MONSTER 486.245071 Yard Vacuum engine overheating?
    • C
      Catherine LopezAug 11, 2025
      If your Craftsman Yard Vacuum engine is overheating, it could be due to: * The carburetor not being adjusted properly. Adjust the carburetor. * Low engine oil level. Fill the crankcase with the proper oil.
  • J
    Jennifer HernandezAug 16, 2025
    How to fix a Craftsman Yard Vacuum that won't discharge?
    • E
      elizabeth62Aug 16, 2025
      If your Craftsman Yard Vacuum isn't discharging, check the following: * The discharge chute (elbow) may be clogged. Stop the engine immediately, disconnect the spark plug wire, and clean the inside of the housing and discharge chute (elbow). * A foreign object might be lodged in the impeller. Stop the engine immediately, disconnect the spark plug wire, and remove the lodged object. * The Vac Cart might be full. Empty the cart.
  • W
    willieknightAug 23, 2025
    What causes excessive vibration in a Craftsman MONSTER 486.245071 Yard Vacuum?
    • L
      Lisa NewmanAug 23, 2025
      Excessive vibration in your Craftsman Yard Vacuum may be caused by loose parts or a damaged impeller. Stop the engine immediately, disconnect the spark plug wire, and then: 1. Tighten all bolts and nuts. 2. Make all necessary repairs. If the vibration continues after these steps, have the unit serviced by an authorized service dealer.

Summary

Warranty Information

Limited Warranty on Tractor Attachments

Details the one-year warranty for tractor attachments, covering defects in material or workmanship.

Limited Warranty on Battery

Covers the ninety-day warranty for defective batteries included with the equipment.

Safety Guidelines

General Safety Rules and Precautions

Essential safety instructions for operating the Vac System safely and preventing injury.

Hazard Warnings and Safe Practices

Highlights critical dangers, warnings, and safe practices for operation.

Accessories and Parts

Accessories and Attachments

Describes optional accessories available for the Vac System.

Hardware and Parts Lists

Detailed lists and diagrams of hardware and replacement parts for the unit.

Carton Contents

Lists the items included in the product's packaging.

Assembly Instructions

General Assembly Steps

Covers the initial steps for assembling the main components of the Vac System.

Cart Cover Assembly

Detailed steps for assembling the cart cover structure.

Deck Adapter Assembly

Instructions for attaching the deck adapter to the mower deck.

Operation and Maintenance

Vac System Overview and Controls

Familiarizes the user with the Vac System's controls and basic functions.

Starting, Stopping, and Emptying

Guides on how to start, stop, and empty the Vac System's collection cart.

Maintenance and Troubleshooting

Outlines regular maintenance tasks, schedules, and how to resolve common operational problems.

Specialized Guides and Parts

Storage and Optional Use

Advice on storing the unit and its optional functionalities.

Repair Parts List

Detailed diagrams and lists of all replacement parts for the unit.

Slope Operation Safety

Provides guidance on safely operating the tractor with the attachment on slopes.

Craftsman MONSTER 486.245071 Specifications

General IconGeneral
BrandCraftsman
ModelMONSTER 486.245071
CategoryYard Vacuum
LanguageEnglish
