Craftsman WS410 User Manual

9
Fig. 7
Strap
Buckle
Clip
Fig. 8
Clip
Fig. 9
Strap
Buckle
Center
Slot
Lower Slot
INSTALLING THE SHOULDER STRAP (OPTIONAL)
1. Push the strap up through the center slot in the buckle (Fig. 7).
2. Bend the strap over and push it down through the lower slot in
the buckle (Fig. 7).
3. Put the shoulder strap over the operator’s head and onto the left
shoulder.
4. Start the unit. Refer to Starting and Stopping.
5. Snap the clip onto the shoulder strap / harness loop (Fig. 8).
6. Adjust the shoulder strap to fit the operator (Fig. 9). Pull the
buckle up to loosen the shoulder strap. Pull the strap down to
tighten the shoulder strap.
Shoulder Strap
/ Harness Loop

Craftsman WS410 Specifications

General

Engine	2-cycle
Engine Displacement	25cc
Cutting Swath	17 inches
Shaft Type	Straight
Fuel Type	Gasoline
Type	String Trimmer
Power Source	Gas-powered
Cutting System	Dual-Line
