1. Mark the position of the mounting screws on the wall using a pencil.
2. Drill the supplied screws directly into the marks that you have made on the wall
and leave approx. 0.3 inch length to hook the sound bar.
3. Put the sound bar onto the mounting screws. Make sure they are firm and stable.
4
You may use
2 pieces plastic inserts
(Included)
2 pieces screws
(Included)
1. Mark the position of the mounting screws on the wall using a pencil.
3. Insert the supplied plastic inserts into the holes by hammer .
5. Put the sound bar onto the mounting screws. Make sure they are firm and stable.
(1)
(2)
4. Secure the supplied screws into the plastic insert and leave approx. 0.3 inch
2 pieces screws
(Included)
2.2 Mounting on the wooden wall:
You may use
2.2 Mounting on the wall
2.1 Mounting on the wooden wall
length to hook the sound bar.
( Not Supplied )
2. Drill 2 x 7/32 inch diameter holes by a powerful electric drill ( Not Supplied ).
22.36 inches (568mm)
22.36 inches (568mm)
