Start-Up
Unless otherwise indicated, these
instructions cover the basic EPRO-
150 to 8000 systems as well as the
“P”, the “XP”, the “A”, and the “WM”
series. When following instructions
please refer to the appropriate
pictures and diagrams depicting
your EPRO system.
The Diagram of the EPRO-150 to
1200 is FIG. 3 on page 16.
The Diagram of the EPRO-1500
to 8000 is FIG. 4 on page 17.
The Diagram of the “XP” Series is
FIG. 5 on page 20.
The picture of the “A” Series is
FIG. 6 on page 21.
The picture of the “P” Series is
FIG. 7 on page 21.
The picture of the “WM” Series is
FIG. 8 on page 22.
The Picture of the “XP” Series is FIG.
9 on page 22.
INSTALLATION
The EPRO reverse osmosis systems,
with the exception of the wall-
mounted units, are free standing and
require no special installation;
however, if placed on an uneven
floor, the system may vibrate. If this
occurs, place the system on a
rubber mat to reduce the vibrations.
For wall-mounted units, attach the
system to the wall securely
(hardware not provided). Additional
instructions for “XP” series
installation are provided on page 18
and 19.
Carefully inspect your system before
start-up. Check all plumbing and
electrical connections. Connections
may have loosened during shipment.
The following hoses are shipped
loose to assist in installation:
A 10’ clear braided inlet hose.
A 10’ poly tube permeate
hose.
A 10’ poly tube concentrate
hose.
START-UP
The 5-micron filter cartridge is
shipped separate from it’s housing.
Steps 1-6 cover installation of this
filter.
1. Locate the 5-micron pre-filter
housing (FIG. 4 or pointer 1 on
the picture or diagram of your
EPRO system). Unscrew the filter
housing. If necessary, use a
spanner wrench (not provided).
Note: Water may spill from the unit
when the housing is removed. Place
a bucket below the housing to catch
the water.
2. Remove the rubber O-ring from
the groove located below the
threaded part of the housing.
Remove any dirt and old lubricant
with a clean rag.
