Crane S002391 - Technical Parts List

service@actionspares.com.au
MODEL: S002391 PRODUCT CODE: 14498 06/2020
AFTER SALES SUPPORT
1800 465 070
31
Technical Parts List
Part No. Description QTY
1 Main frame 1
2 Front stabilizer 1
3 Rear Support 1
4 Console post 1
5 Console plate 1
6 Handle bar 1
7 Small pulley 1
8 Pedal axle 2
9 Pedals gap tube 2
10 Rear support tube 1 1
11 Saddle carrier 1
12 Textile rope xer 1
13 Rail enformcemnt 1
14 Rail connecting tube 1
15 Textile roller gap 4
16 Fan rower axle 1
17 Sliding rail 1
18 Adjust knob 1
19 Tension control knob 1
20 Wheel adjuster 2
21 Hook screw 2
22 Washer pwoder 2
23 Small spring 1
24 Bearing 4
25 M8 nylon cap 01 2
26 M10 nylon cap 3
27 Pull pin 1
28 Nylon nut 1
29 Screw 1/2*100 1
30 OD 22 *ID13 *2.0T at washer 4
31 OD 32 *ID13 *2.0T at washer 1
32 M12 nut 1
33 6001 ZZ bearing 2
34 Semi - circle button 2
Part No. Description QTY
35 M8*60 screw 2
36 OD 20 *ID8.5*1.5T at wsher 18
37 M8 nut cap 4
38 M8 nylon cap 12
39 M10 *20 screw 2
40 OD 14 *ID10 .5*1.5T at washer 6
41 M10 *65 screw 1
42 M6*80 at cross head bolt 2
43 M6*10 round cross head screw 4
44 M8*20 screw 8
45 M8*32 blunt screw 4
46 M8 split washer 8
47 M6*16 round cross head screw 9
48 M6 nylon cap 1
49 M5*15 at cross screw 2
50 M3*10 self tapping screw 1
51 Wheels 4
52 OD 16 XID 6.5X1.5T at washer 9
53 OD 16 XID 8.5X1.5T at washer 4
54 M4*16 self tapping screw 31
55 Round cross M5*25 screw 1
56 OD 12 XID 5.5X1.0T at washer 1
57 Left shield 1
58 Right shield 1
59 Rope protective 1
60 Console post base 1
61 Air fan exit 1
62 Pedals 2
63 Belt plate 1
64 Pulling rope 1
65 6000 ZZ 2
66 HF 1716 bearing 1
67 Spring base 1
68 Spring cover 1
