MODEL: S002391 PRODUCT CODE: 14498 06/2020
AFTER SALES SUPPORT
1800 465 070
9
Hardware Identification Chart
Use the drawings below to identify the hardware needed for assembly. The number in parentheses
below each drawing is the part number.
NOTE: If a part is not in the hardware kit, check to see if it has been pre-assembled.
Step 2 Step 1
Step 5 Step 4
Step 3
Step 6
(40) OD14*ID10.5* 1.5 T
hexagon screw - 2pcs
(44) M8*20 screw - 4pcs
(36) OD20*ID8.5* 1.5T
(30) OD22*ID13*2.0T
(36) OD20*ID8.5*1.5T
(100) Screw cover-1pc
(31) OD32*ID13*2.0T
(83) saddle carrier
PP blocker-2pcs
(50) M3*10 self stapping
screw - 1pc
(43) M6*10 round cross
head screw - 1pc
(54) M4*16 self tapping
screw - 1pc
(47) M6*16 round cross
head screw - 2pcs
(86) wire plug-1pc
(46) M8 split washer
- 4pcs
(9) pedals gap tube- 2pcs
5MM allen wrench
6MM allen wrench
Multi-functional spanner
Spanner screw driver
