Crate CA6110D User Manual

www.crateamps.com
©2004 SLM Electronics
A Division of St. Louis Music Co.
1400 Ferguson Avenue
St. Louis, MO 63133
47-941-04 • 021704
CA6110D Acoustic Amplifier
Technical Specifications:
Crate continually develops new products, as well as improves existing ones. For this reason,
the specifications and information in this manual are subject to change without notice.
Output Power Rating: 60 watts @ <1% THD
Channels 1 & 2: Low: +/-15dB @ 80Hz
Mid: +15, -30dBdB from 450Hz – 1.2kHz (Contour)
High: +/-15dB @ 10kHz
Input Impedance: 3.3M ohm High-Z, 3k ohm Low-Z
Input Sensitivity: 5mV High-Z, 2mV Low-Z
Sens. to Eff Send/Line out: 6mV High-Z, 3mV Low-Z
Max Input Signal: 6V RMS (17V peak to peak)
CD
Input: Input Impedance: 22k ohm
Input Sensitivity: 150mV
Max Input Signal: 6V RMS (17V peak to peak)
AuxEff. Return: Input Impedance: 11k ohm
Input Sensitivity: 60mV RMS
Max Input Signal: 6V RMS (17V peak to peak)
Eff Send Out. Impedance: 2.2k ohm
Line Out Out. Impedance: 220 ohm Low-Z, 2.2k ohm High-Z
Feedback Filters: 10Hz to 4.8kHz range, -15dB cut per filter
Internal Woofer: 10” w/polypropylene cone, rubber surround, 30.5oz magnet, 1.5” voice coil,
8 ohms, 75w RMS, 95dB 1w 1m
Internal Tweeter: High efficiency Piezo, 110dB 1w 1m
Internal Crossover: Passive type
Power Requirements: 120VAC, 60Hz, 70VA
100/115VAC, 50/60Hz, 70VA
230VAC, 50/60Hz, 70VA
Size and Weight: 17”H x 16”W x 14”D, 37 lbs.

Crate CA6110D Specifications

Power Specifications

output power rating	60 watts @ <1% THD
power requirements	120VAC, 60Hz, 70VA, 100/115VAC, 50/60Hz, 70VA, 230VAC, 50/60Hz, 70VA

Audio Input/Output

input impedance	3.3M ohm High-Z, 3k ohm Low-Z
input sensitivity	5mV High-Z, 2mV Low-Z
sens. to eff send/line out	6mV High-Z, 3mV Low-Z

Internal Components

internal woofer	10” w/polypropylene cone, rubber surround, 30.5oz magnet, 1.5” voice coil, 8 ohms, 75w RMS, 95dB 1w 1m
internal tweeter	high efficiency Piezo, 110dB 1w 1m
internal crossover	passive type

Size and Weight

height	17”
width	16”
depth	14”
weight	37 lbs
