The Front Panel (continued):
6. Line Out: Use this jack to send a line level
signal from the amplifier to a mixing board,
external amplifier or powered monitor, or a
recording device.
WARNING: Do not attempt to use
headphones in the Line Out jack!
7. Power: Use this switch to turn the amplifier
on (toggled down) and off (toggled up). The red
lamp above the paddle illuminates when the
amplifier is turned on.
The Rear Panel (not shown):
8. AC Line Cord: The grounded power cord
should only be plugged into a grounded power
outlet that meets all applicable electrical codes
and is compatible with the voltage, power, and
frequency requirements stated on the rear
panel. Do not attempt to defeat the safety
ground connection.
CRATE CR-1 LIMITED EDITION GUITAR AMPLIFIER
55
