Need help?Do you have a question about the Crate EXCALIBUR GX-900H and is the answer not in the manual?
Power| input power requirements | 120VAC, 60Hz, 240 watts max. |
|---|
Output| output power rating | 90 watts RMS @ 5% THD, 2 ohm load |
|---|
Fuse| fuse rating and type | 2A Normal Blo, 250V Internal, 100VAC-120VAC; 1A Slo Blo, 250V Internal, 230 VAC |
|---|
Cabinet| cabinet size | 11.63” H x 30.75” W x 11” D |
|---|---|
| weight | 35 lbs. |
Power| input power requirements | 120VAC, 60Hz, 500 watts max. |
|---|
Output| output power rating | 220 watts RMS @ 5% THD, 2 ohm load |
|---|
Fuse| fuse rating and type | 5A Normal Blo, 250V Internal, 100VAC-120VAC; 3A Normal Blo, 250V Internal, 230VAC |
|---|
Input| maximum input signal level accepted | 8 volts peak to peak |
|---|---|
| input impedance | 470 k ohms |
System Gain| total system gain channel B | 54 dB @ 1 kHz, all controls at “10”, Bright off |
|---|---|
| total system gain channel A gain one | 69 dB @ 1 kHz, all controls at “10” |
| total system gain channel A gain two | 86 dB @ 1 kHz, all controls at “10” |
Channel B| low | 25 dB range @ 70 Hz |
|---|---|
| mid | 14 dB range @ 800 Hz |
| high | 29 dB range @ 10 kHz |
| bright | 7 dB boost @ 10 kHz |
Channel A| low | 18 dB range @ 100 Hz |
|---|---|
| mid | 10 dB range @ 1 kHz |
| high | 17 dB range @ 6 kHz |
