Page 21Vortex8 User Manual
Version 1.0
COLOUR MODE
CCT White light with variable colour temperature and green/magenta control
HSI Vivid colours with Hue and Saturation control
RGBW Direct control of Red, Green, Blue and White channels
XY Calibrated colour control using X,Y coordinates
GEL Select from over 300 industry standard lighting gels
CCT-HSI Crossfade betweeen CCT and HSI modes
CCT-RGBW Crossfade between CCT and RGBW modes
CCT-XY Crossfade between CCT and XY modes
CCT-GEL Crossfade between CCT and GEL modes
EFFECTS MODE
No Eect All eects disabled
Candle & Fire Realistic candle are firelight eect with control over preset, intensity, speed and colour
Emergency Lights Emergency lights such as police and ambulance with control over preset, colour, flashes, speed and pause
time
Television Changes CCT and green/magenta to simulate light cast by TV screen, with control over speed, dynamic range
and CCT
Party Dynamic colour changing party lights with control over pallete, speed, transition type and transition speed
Pulse Pulse of light fading in and out with control of frequency and pulse speed
Paparazzi Random camera flash-bulb eect with control of speed, decay speed and CCT
Colour Cycle Cycle through the spectrum of saturated colours with control over speed
Strobe Strobe eect with control over frequency, brightness & duty cycle
Random Create a random pattern of flashes with control over frequency, length & variation
Dual Level Set two dierent light levels and instantly switch between then using Flash button, DMX or external trigger
signal
PRESET
Select from a range of CCT and Colour presets for recall of commonly used colours
FIXTURE SETUP
FAN MODE Auto - Variable speed fan control based on temperature of fixture
Quiet - Fans run at constant low speed
Medium - Fans run at constant medium speed
High - Fans run at constant high speed
Pause - Fans are stopped temporarily until until fixture heats up (should not be used for long periods of time)
5.7 Menu Functions Cont.
5. Controls
