Page 22Vortex8 User Manual
Version 1.0
FIXTURE SETUP
DIMMING CURVE Linear - Linear dimming curve
Exponential - Smoothest dimming at low levels
Logarithmic - Smoothest dimming at high levels
S Curve - Smoothest dimming at low and high levels
Calibrated RGBW Activate calibrated colour space for RGBW modes. This uses the Kodak Pro Photo Colour Gamut / Plasa
standard E1.54. The white point is set to 3200K
High Speed Enables High Speed mode for shooting at high frame rates. Disable for best colour accuracy and dimming
performace
DMX SETUP
DMX Address Set DMX Address from 1 to 508
DMX Mode Choose active DMX Mode
DMX Smoothing O - No smoothing is applied to DMX data, fastest response time
Smooth - Interpolation over two DMX frames for smooth dimming, reduced response time
Super Smooth - Interpolation over five DMX frames for super smooth dimming, slow response time
LINK
LumenRadio Unlink Unlink LumenRadio from all transmitters (shortcut - hold LINK button for two seconds)
LumenRadio Enabled Enable or disable LumenRadio receiver
DMX SETUP Shortcut to DMX SETUP Menu
Master Mode When enabled this unit will act as a master and transmit colour data over DMX port to other Creamsource
fixtures
ADVANCED
EXTERNAL TRIGGERING Trigger Disabled - No external triggering over Accessory Port
Trigger Eects - External trigger signal used to trigger eects (same as Flash button on keypad)
Virtual Shutter - External trigger signal used to shutter light ON/OFF (fastest response time)
Information Show system information such as Serial Number, IP Address, Hardware type
Restore Defaults Restore all fixture settings to the factory defaults
5.7 Menu Functions Cont.
5. Controls
